Taifun Box

Taifun Box Mod

The Taifun Box is an electronically controlled and regulated advanced personal vapourizer power supply device, for use with atomizers with a diameter up to 25mm. It is powered by a single 18650 lithium battery and has an output power of up to 80 Watts through its fully customized Dicodes chip set.

The Dicodes chip set used within the Taifun Box is a fully German engineered and fabricated board is a fully customized version by Taifun, that makes the Dicodes user interface so much more usable, while keeping all of the great features that Dicodes boards are known for, such as:

• Outpput power up to 80 Watts
• Battery internal resistance monitoring to warn against battery overload
• 0.91" OLED display shows the most important parameters during and after vaping
• Uses three buttons to fire and adjust the settings in the menu
• 5 different operating modes:
  • Power (VW)
  • Power Boost
  • Temperature Control
  • Pulse
  • Bypass (electronic regulation off)

Features:

• Power range: 5 to 80 Watts with a high drain 18650 lithium battery
• Battery discharge voltage cut off at 2.5 Volts
• Immediate wake up when in automatic standby mode
• No power consumption after automatic standby shutdown
• Up to 11 volt output voltage
• Up to 22 Amp output current
• Spring loaded copper beryllium center pin in 510 connector
• Temperature controlled vaping with ResisTherm and all common wire types as well as custom wire types (through adjustable TCR)
• Resistance Range (80W): 0.17 to 1.5 Ohms
• Total resistance range: 0.1 to 3.0 Ohms
• Battery internal resistance measurement
• Menu assistant for a user friendly operation
• 5 operating modes: Power, Boost, TC, Pulse, and Bypass
• Reverse polarity protection
• Spring loaded battery positive pole with 4 contacts for optimum power consumption
• Battery charging contact at the bottom
• Buttons and side panels interchangeable. Optional accessories sold separately, will be announced when available.
• High quality case materials: Stainless steep top and bottom caps with anodized aluminum body and plates.

Dimensions:

• Width: 40mm
• Length: 81mm
• Depth: 25mm
