  • Taifun GX RDTA 4ml

click on thumbnail to zoom
Other products by Taifun
Item #: VA11323
Our Price: $179.99
Quantity:
  (max 1)
In Stock

Description

Taifun GX Specifications:

  • Diameter: 23mm.
  • Liquid Capacity: 4mL
  • Height (4mL, including 510 connector): 45mm.
  • Tank Material: Borosilicate glass (clear).
  • Stainless steel construction.
  • Interchangeable Air Flow Disks.
  • RDTA style, can be used with or without SS cables. Usage with the stainless steel braided cables are recommended for fastest wicking.
  • SS Feeder Cable Length: 23mm.
  • Two air disks included, each with three 1.8mm air holes for a total of six 1.8mm air holes.
  • Friction Fit SS/POM combination BTD style 510 Drip Tip included, for maximum air flow. No o-rings are used for this drip tip.

Included:

  • Taifun GX atomizer
  • Two air disks, each with three 1.8mm air holes
  • Two SS feeder cables
  • Supplement with replacement o-rings, screws, and allen key
  • Instruction manual

Taifun GX by SmokerStore

The Taifun GX is a rebuildable top deck atomizer featuring a flavour-focused interchangeable air flow system, easy-build coil winding deck, and SS liquid feeder cables to quickly deliver liquid to the deck down to every last drop in your tank!

Available in one of two sizes for different liquid capacity:

  • 2ml
  • 4mL

(Note: Photos shown below have a prototype PSU tank, as the clear glass tank was not yet available at the time these photos were produced.)

Taifun GX

The Taifun GX is the first top-deck atomizer design of the Taifun in-house genealogy, allowing for the best flavour possible, performing like the taifun BTD, but with the capacity of a tank. Designed for variable use, the possibilities for vapers with regards to individualization and adaptation to their own requirements is now possible.

Taifun GX Design

Easy Access Build Deck

The Taifun GX features a modular structure that allows the build deck to be removed from the lower tank and airflow section to allow easy user access to the wicks and the changeable air disks.

Taifun GX Removeable Build DeckTaifun GX Air Disk and Wick Access



Interchangeable Air Flow Inserts

The Taifun GX is designed so that customers do not need to adjust to an atomizer. Rather, the atomizer can be adjusted to fit the user. The basic principle is that the Taifun GX cannot be narrowly defined or categorized as a "MTL", "RDL", or "DL" type of vaping experience. Rather, an interchangeable Air Flow Disk system allows users to modify the airflow as required, making the Taifun GX a truly versatile atomizer to fit a wide range of vapers. The only thing that the Taifun GX can NOT do, is high wattage, high airflow vaping, nor does it want to be.

The Air Disks allow for a wide range of possibilities and are easily changed. The basic version of the Taifun GX includes two Air Disks, each with three 1.8mm air holes for a total of six 1.8mm air flow holes. This makes the Taifun GX slightly more restrictive than the Taifun GT IV. However, the Taifun GX can also be operated without any Air Disks for maximum air flow, and will deliver a little bit more air flow than the Taifun GT IV with the open draw positive pole.

Air flow of the Taifun GX is adjusted completely with the internal Air Disks, and cannot be adjusted much from any external air flow control ring.

Taifun GX Interchangeable Air Flow Disks

Secure Top Cap Design

Featuring the bayonet lock as previously introduced with the top fill cap of theTaifun GTR, this design prevents accidental removal of the top cap.

Concave inner cap design also allows for smoother airflow and better flavour production.

Taifun GX Top Cap Design



Multi-Function (MF) Ring

A multi-function (MF) ring is integrated in to the Taifun GX, allowing users to adjust the atomizer for various usage modes, and snaps into place with a satisfying click so the user has security in the mode it is set to. The modes available are:

Taifun GX MF Ring DL Vaping Position

DL Vaping Position

Air flow is fully open, and tank reservoir is fully open for ventilation. Ideal for DL vaping and higher VG e-liquids where fast liquid transport is required.







Taifun GX MF Ring Transport Setting

 Transport Lock

Air flow is closed, and liquid flow is sealed. The tank is effectively sealed when in this mode, and is ideal for transporting the atomizer to prevent any liquid leakage.







Taifun GX MF Ring Fill Setting

Filling Position

In this position, the Taifun GX can be easily and quickly filled from the outside, without the need to remove the top cap. An alternative base with a larger fill hole will be available for separate purchase, and is ideal for maximum VG users.







Taifun GX MF Ring MTL Setting

MTL Vaping Position

In this mode, the air flow is open, but the ventilation to the e-liquid reservoir is closed. Liquid now exclusively travels along the SS feeder cables via capillary action, and reservoir air resupply is choked. This prevents over saturation of the cotton wick when using higher PG liquids, as negative pressure vacuum is higher in the chamber when vaping with more restricted air flow.
