USERS GUIDE:
Normal operation watt setting: The power level currently set on the DNA 30D. Battery indicator: The current state of charge of the battery.
Volts display: The output voltage being supplied to the atomizer.
Ohms display: The resistance of the atomizer attached to the device. This is measured only when the unit is supplying power to the atomizer. At other times, it shows the most recent measurement.
Other modes:
Locked mode: Pressing the fire button five times with less than .7 seconds between presses will cause the device to enter Locked mode. In Locked mode, the device will not fire and the output power will not adjust accidentally. While in Locked mode, the screen will be off, except that pressing a button will show “Locked, Click 5X”. To exit Locked mode, press the fire button 5 times.
Stealth mode: While locked, pressing the fire and down buttons simultaneously for five seconds will switch to stealth mode. In this mode the display is off. It will still show error and lock messages. To switch back to normal display mode, hold down the fire and down buttons simultaneously for 5 seconds. This setting is stored to internal flash memory, and remains if power is removed.
Right mode & left mode: While locked, holding the fire and up buttons simultaneously for 5 seconds flips the display. This setting is stored to internal flash memory, and remains if power is removed.
Power locked mode: Holding down both the up and down buttons for two seconds will place the device in Power Locked mode. In this mode, you will not be able to change the power setting. This mode prevents accidental power level changes due to the buttons being pressed while in a pocket. To exit Power Locked mode, hold the up and down buttons for two seconds.
Error Messages: The DNA 30 will indicate a variety of error messages, as follows:
Check atomizer: The DNA does not detect an atomizer, the atomizer has shorted out, or the atomizer resistance is incorrect for the power setting.
Shorted: The atomizer or wiring are short circuited.
Check battery: The battery is below 3.1 volts. It probably needs to be charged.
Weak battery: The battery sags excessively when firing. This typically means the user is not using a high rate battery, or the battery is old and degraded. It can also mean the battery is not making good contact.
Too hot: The DNA 30D has onboard temperature sensing. It will shut down and display this message if the internal board temperature becomes excessive.
Too low power setting: The DNA 30D puts out a minimum of 4 volts. With low power settings (7 to 8 watts) and low resistance atomizers (below 2 ohms) the DNA will sometimes be unable to provide a low enough power output to be power regulating. If this is the case, the Ohms display will be flashing. The device will still operate.
Device resets: If the battery is not able to power the device at the desired setting, or the battery is excessively discharged, the device may go immediately into a low voltage shutdown. If firing the device causes the screen to blank out and then display the welcome screen, you should charge, replace or upgrade your battery. This is especially common at power settings above 20 watts.
Auto power down: The screen will be at full brightness while firing. After 15 seconds with no button presses, the screen will dim. 2 minutes after the last button press, the screen will fade out and the device will go to sleep mode. Pressing any button will turn the device and display back on.
